1997 STIEGLER ST-1/3 900 W-L (V1)– WICKET BAGS – BLOCKED BAGS – Punch

No longer available

1997 STIEGLER ST-1/3 900 W-L (V1)– WICKET BAGS – BLOCKED BAGS – Punch

Available quantity: 1

Description

Material type: LDPE; LLDPE (Borstar); HDPE; pp Cast

Foil type: sleeve, half sleeve, foil, bottom gusset, fold; perforatin

Bag type: punch, blocking; longitudinally sealing; adhesive tape

Unwinder: width max.1.500 mm

Sealing type: welding strip 1,4 mm

Width of the sealing bar: 950 mm

Speed of Machine: min. 30 pcs/min – max. 250 pcs/min

Bag width: - min. 120 mm - max. 605 mm

Thickness: - min. 15 my - max. 150 my

Bag height: - min. 250 mm - max. 750 mm

Botttm gusset: min. 27 mm – max. 100 mm

Keeping the foil trough the machine: double-sided FIFE (on the machine)

Foil trim: YES

Core diameter: Ø 76 mm

Roll diameter: max. 800 mm

Printed foil: photocell

Product ventialtion: a) hole – YES b) cross - YES

Techical documentation:- Electrical plan - Instructions for use - drawings

Available for dismantling in October 2021

Specifications

ManufacturerSTIEGLER
ModelST-1/3 900 W-L (V1)– WICKET BAGS – BLOCKED BAGS – Punch
Year1997
ConditionUsed
