1992 UTECO CORAL 675 140 - (C.I 6 col. Flexo 1400 mm)

1992 UTECO CORAL 675 140 - (C.I 6 col. Flexo 1400 mm)

Available quantity: 1

orCall +39 346 4948054

Description

Manufacturer: UTECO

Model: CORAL 675 140

Year1992

Number of colors: 6

Web width: 1450 mm

Print width: 1400 mm

Print repeat (min - max): 320 - 800 mm

Mechanical speed: 250 m/min

Rewinder max diameter: 1000 mm (unwinder turret type - non stop automatic)

Unwinder max diameter: 1000 mm

Web tensioin controlled by pneumatic brake and dancing roller

All 6 station with closed chamber doctor blades

6 ink pumps

Drying system with 4 fans, tunnel 3mt length, 1 gas burner

VideocameraYes, BST 3 ccd (new)

10 ceramic laser engraved anilox rollers

1 web guide bst

4 sets of print cylinders with gears (40 - 46 - 50 - 60 cm)

1 rubber roller complete of supports to be mounted on station 1

Thermo conditioning unit with chiller for CI drum and chill roller

Rotary knives slitting attachment at rewinder with trim exhaust

2 spaer chamber holders for doctor blades

1 spare new PIV transmission box for outfeed calendar

1 spare anilox clutch

Machine dismantled in June 2022 (it was in production) and no longer visible in operation.


Specifications

ManufacturerUTECO
ModelCORAL 675 140
Year1992
ConditionUsed (visible in production)
