1980 Titan SR5 Slitter rewinder (1300 mm)
1980 Titan SR5 Slitter rewinder (1300 mm)
Posizione:Europa
Disponibilità in magazzino:1
o
Chiama +39 346 4948054
Descrizione
Used Slitter rewinder Titan Model: SR5 year 1980.
The Machine was improved and refurbished in 2011. In addition was installed a new brake system (Pneumatic Disk Re-Spacex 250 Combiflex) and a new web guide(Fife Maxcess Polaris DP-30)
The machine can cut fillm or paper reels.
Current condition: Disconnected. Can't be seen in operation.
Availability: Immediate
Specifiche
| Produttore | Titan |
| Modello | SR5 Slitter rewinder (1300 mm) |
| Anno | 1980 |
| Condizione | Used (assembled but no longer visible in production) |
| Type | Slitter rewinder |
| Working Width | 1300 mm |
| Final Roll Diameter | 600 mm |
| Speed | 250 m/min |
| Web Guides | Fife Maxcess Polaris DP-30 |
| Brake system | Pneumatic Disk Re-Spacex 250 Combiflex |
| Knife Type | Razor |
| Slitting Width (Min) | 80 mm |
| Roll Core Diameter | 76 mm |
| Material | Paper / film |
| Max pneumatic | 7bar |
| Voltage | 380 V Triphase |
| Frequency | 50 Hz |
| Additional information | Machine improved and refurbished in 2011. In addition was installed a new brake system (Pneumatic Disk Re-Spacex 250 Combiflex) and a new web guide(Fife Maxcess Polaris DP-30) |
| Visible in operation | No - Disconnected. Can't be seen in operation |
